DESCRIPTION

Basic Info

Model NO.	15K or 20KHZ
After-sales Service	Life Long Maintenance, 1st Year for Free
Main Oversea Market	North America, Europe, Southeast Asia, Middle East
Applications	Nonwoven, Plastic, Clear Case, Velcro, File
Material	HDPE, ABS, ROM, PP, PC, PVC
Other	Sealing, Welder, Ultrasonic Generator
Transport Package	Wooden Package
Specification	70*80*125
Trademark	DIZO
Origin	China
HS Code	8515809090
Production Capacity	5000

Product Description

Ultrasonic Welding Machine Clear Case Sealing Slab Bonding Machine for mask nonwoven plastic pokemon card case gift card holderWuxi Dizo Ultrasonic Technology 20 Years Experience in ultrasonic equipment,15 Years Manuafacturer foundation in China,Provide customer professional plastic welding solutions

Product Description
Ultrasonic plastic welding machine is widely used in automobile industry, electronic industry, medical industry, home appliance industry, non-woven clothing, office supplies, packaging industry, toy industry and so on.For example, car body plastic parts, car doors, car gauges, car lights, mirrors, sun shades, interior trim, filters, reflective materials, reflective road nails, bumpers, cable, motorcycle plastic filters, heat dispersors, brake fluid tanks, oil cups, water tanks, fuel tanks, air pipes, tail gas purifiers, tray filters;Plastic electronics: Prepaid water meter, electricity meter, communication equipment, cordless phone, mobile phone accessories, mobile phone case, battery case, charger, valve controlled seal maintenance lead-acid battery, 3-inch floppy disk, U disk, SD card, CF card, USB connector, Bluetooth;Toy stationery: folder, album, folding box, PP hollow board, pen set, ink box, toner cartridge,Medical daily: watches, kitchen utensils and appliances, oral liquid bottle caps, drip bottle caps, mobile phone accessories, king soft brush, daily necessities, health supplies, children's products, air mattress, hangers, handle, garden supplies, kitchen ware, showers, king soft brush, shower head, anti-fake bottle, cosmetic bottle, coffee pot, washing machines, air dehumidifier, electric iron, electric kettle, vacuum cleaner, speaker wooden grille metal surface cover and soil, etc



Product Description--technical parameters of ultrasonic welding machine

Service:	OEM/ODM
Voltage:	110V/220V
Power:	1800W/2600W/3200W/4200W Depend on Usage
Frequency:	15KHz/20KHz/30KHz/40KHz/60KHz/70KHz Depend on Usage
Material:	PS, PMMA
Application:	PSA Card, Grading Card, Sports Card, Card Slab etc.Plastic Card Seal Welding
Welding Area:	Customize Square width 80-320mm, Round 25-95mm diameter
Delay Time/Weld time/Hold Time:	0.01~9.99S
Driven Mode:	Pneumatic
Max air pressure:	0.7MPa
Maximum Stroke:	75mm
Operation Mode:	Semi-automated
Display:	Intelligent Digital
Weight:	100-220KG Depend on Usage
Material:	Aluminum
Material of welding horn:	Magnesium Aluminum Alloy/Titanium Alloy/Steel Alloy
Core selling points:	Accurate temperature control/Flexible Manufacturing/Low Maintenance Cost/Sustainable/Low Noise Level/High Safety Level/Easy to Operate/Long Service Life/High Rigidity/High-accuracy

Working flow
Ultrasonic Working PrincipleUltrasonic welding is to convert 50 / 60 Hz current into 15, 20, 30 or 40 kHz power by ultrasonic generator. The converted high-frequency electric energy is converted into the mechanical motion of the same frequency again through the transducer, and then the mechanical movement is transmitted to the horn through a set of horn device which can change the amplitude. The vibration energy received by the horn is transferred to the joint of the workpiece to be welded. In this area, the vibration energy is converted into heat energy by friction, and the plastic is melted. Ultrasonic can be used not only to weld hard thermoplastic plastics, but also to process fabrics and films. Heat energy comes from the reciprocating movement of a workpiece on another surface with a certain displacement or amplitude under a certain pressure. Once the expected welding degree is reached, the vibration will stop, and at the same time, there will still be a certain pressure applied to the two workpieces to cool and solidify the just welded parts, thus forming a close combination.

CertificateWho are we and what we do ?
Dizo ultrasonic sticks on making ONLY HIGH-QUALITY plastic welding machines for more than 15 years.
Wuxi Dizo ultrasonic technology co,ltd is a high tech company who specialized in plastic welding technology development,manufacturing and sales service of ultrasonic equipment. We improve our customer's competition and creates value by providing high-quality products and excellent services.We adhere the business philosophy of "customer first,Teamwork. Self breakthrough".With development concept of market demand as guidance,technical progress as driving force, customer satisfaction as criterion and the service concept of "Start with customer demand and end with customer satisfaction"we supply best ultrasonic welding equipment and best ultrasonic welding service.
