Products

DESCRIPTION

Basic Info

Model NO.	OBX-310
Voltage	220V
Customized	Customized
Cheese Cutting	Soft Material Cutting Better
System	Simens PLC
Motors	Servo
Cutting Type	Sonic
Transport Package	Wooden Box
Specification	ultrasonic
Trademark	OBAKING/OBESINE
Origin	China
HS Code	8456200000
Production Capacity	500sets

Product Description

OBAKING one-stop cake making machine sets Vertical cake cutter

Product Description

oModel	OBX-450/400	Remarks
Voltage	220V Single phase 50-60hz	Simens system Heating blades Compressed air source neededstainless steel 304 material
Power	1.5kw
Size	1260*1150*1400(mm)
Weight	400kgs

with the Control system Mitsubishi PLC host with man-machine interface and other divided round, square and triangle cakesThe main performance and structural characteristics of the cake cutting machine:1. Cutting multi-layer products can keep the color between layers2. Can be cut: sheet, rectangle, triangle, equal circle3. Wide range of cutting objects, both frozen products and cream products can be adapted4. The cutting model of specific products can be customized according to the needs of customersCakes cutting machine Features:1. Imported tooth-shaped cutters are used, the blades do not contain slag, the chips are less, and they have the functions of removing chips and heating. The cutting surface is fine and the product is high-grade;2. It is suitable for cutting cream cakes, majestic cakes, sponge cakes, sandwich cakes, roll cakes and other cake products; various cutting methods: square, triangle, slice;3. LCD touch screen and Japan's Mitsubishi PLC control, with 40 groups of memory formulas, formulas can be set freely, and the operation is simple.

Detailed Photos

OBAKING -The ultrasonic food cutting equipment is composed of an ultrasonic transducer, a housing, a horn, a titanium alloy knife and a numerical control drive power supply. Ultrasonic food cutting machine is an innovation in food processing. The ultrasonic food cutter vibrates at a high frequency of 40kHz or 20kHz. This high frequency vibration reduces the frictional resistance on the cutting surface. This low friction enables the cutting knife to cut the food smoothly, so that the cutting surface of the food is clean, beautiful, and does not deform. In addition, ultrasonic cutting reduces food fragments during the cutting process. This reduces more downtime to clean up your production system. Ultrasonic food knives can also be easily installed in your current production system to help you better finishing,Usage range:CAKE Ultrasonic cutter machine (1) Cake cutting/cheese cutting (2) Bread and biscuit cutting (with the characteristics of fine cut, no crumb, no slag, and no deformation.)(3) Sandwich cutting (solve the problems of deformation, unevenness, leakage of food materials, and unsightly cut surface during the cutting process of sandwich products.)4) Candy cutting (Solved the problems of sticking knives, melting of candy, and severe tool wear during the cutting process.)ADVANTAGE - Ultrasonic cutting machine to automatically cut slab cakes,biscuit rolls,slab cakes in trays,cheese,dough,fruit bars,round cakes and similar products. - Allow to set multiple cutting modes,including slice,or square, or triangular ,or circle type. - Easy to operate,labor saving. - Open machine design for easy. - PLC control system. - Strong stainless steel 304 machine frame for a rough bakery working day.Product ParametersFeature Fast and precise because of unique servo technology. Advanced software to set product parameters using icons on the touch screen. Set your own cutting pattern (also on the touch screen). A high quality safety system prevents access of the cutting area during operation. For rectangular,triangular and circle products. Movable on 4 swivel wheels. For your convenience available in English languageAdvantages
Multi-layer product cutting, can keep the color between layersAdvantages of ultrasonic cutting: fine cut, no chips, no sticking to the knifeMulti-function type, composed of multiple sets of cutting knives, suitable for product assembly line use.A wide range of cutting objects, both frozen products and cream-containing products can be adaptedThe cutting model of products can be customized according to the needs of customersTechnical Parameter

Model	Specifications	cutting shapes
Voltage	220V/60HZ 50HZ	Round/ square/rectangular,triangular and circle products.
Power	3.5
Size	1800*1050*1750MM
Weight	600KGS
length of blade	1*300/1*150
size	4 inch-18 inch

OBAKING Ultrasonic food cutting system uses ultrasonic energy to cut food with high frequency vibration. The cutting surface is clean, complete, and not deformed. It can also reduce food debris during the cutting process and reduce the time it takes to clean the production system.(1) For precision cutting products that are difficult to process, the cutting part has fusion to prevent loosening of the cut material.(2) The cutting speed is fast and the incision is small, which can effectively reduce the generation of debris. The cutting models for specific products can be customized according to the needs of customers.(3) High-quality materials comply with food industry standards. The equipment is made of stainless steel and titanium materials to ensure hygiene and safety.(4) Abundant cutting shapes: flakes, rectangles, triangles, and equal circles; when cutting, multi-layer products can be cut to keep the layers without color; frozen products and cream-containing products are also applicable.technical supports : WHAT APP +86-13383034008

Packaging & Shipping

FAQ

FAQ:
Q:What's Delivery time after place trial order ?
A: Within 15days-20days as usual .
Q:What are the main market of your products?
A: US ,Janpan UK ,Thailand ,Argentina , Brazil , UAE , Middle east ,north america and Asia ,etc
Q: What's the warranty time or policy after sales ?
A: Two year and free spareparts to be proived during this periond and free training for whole lifetime .
Q: What's the Services for installation ?
Online tecnnical supporting,or send engineers on site .Vedio manuals, Provides oversea installation Services
